SensaSound IW/OW custom installation series products are the latest products, Professional family from voice first design concept, design unit USES boldResearch and development of innovative solutions, the entire series adopt new RG super high, higher sensitivity, penetration and directivity more accurate; Thin body, embedded, wall hangingDesign to meet different customer needs. Closed to the super hybrid mask resonance cavity collocation, sound better, stealth embedded and joint type of hanging wall hole, installation is convenient.
Patented Customized Tweeter
It spent Sensasound two years to specially designed and developed the new Rocket Gun Tweeter. This super tweeter has a very high energy output and is especially suitable for customized theater with the sound-transmitting curtains in the front.
Various Installation Methods
Sensasound IW loudspeakers are designed for dual installations that can be either "wall mounted" or "in-wall". It is specially developed according to the needs of different markets in China and the United States and is suitable for various installation situations.
Specially Designed Cabinets
Sensasound IW series are designed with their own back cabinets. As we all know, if the embedded loudspeaker has its own back cabinet, the overall sound effect will be better. The IW500 has designed a special dual-structure back cavity for separate high and low frequencies. The treble part is a common closed back cavity, and the bass part is designed with an unprecedented porous mesh type back cavity, which can improve the sensitivity of the bass part to better match the sound pressure of the treble part. It can be said to be a major breakthrough that pioneered the development of embedded loudspeakers.
SPECIFICATION | |
Frequency Response | 20Hz-20KHz |
Sensitivity | 96dB |
Impedance | 4Ω |
Power handling | 200W |
Tweeter | 1’’ RG tweeter |
Mid range | Two 4’’ Paper Cone Drivers |
Woofer | Two 8’’ Paper Cone Drivers |
Dimensions( H*W*D) | 15.87''*43.11''*4.29''(403*1095*109mm) |
Cut Out (H*W) | 14.53‘’*41.77‘’(369*1061mm) |
Grill | Customized |
